Electric 4x4 farm vehicle

Vehicle model : Cubs W2S

Specifications

Overall dimensions

2860 x 1534 x 1430mm

Cargo / Dump bed

885 x 1438 x 270mm

Wheel base

1920mm

Wheel track

1220mm

Min. ground clearance

300mm

Weight Data

Persons in cab

3 persons

Curb weight

478Kg

Battery weight

432Kg

Payload

650Kg

Gross vehicle weight

1560Kg

Performance

Max. speed

40Km/h

Max. slope of climb

30%

Min. turning radius

4m at 30km/h

Max. driving range

140km based on weather and road status

Power system

Driving mode

4 x 4 / 2 differential lock, manually switch

Electric motor

High work efficiency AC motor

Power voltage

72V

60V, 72V

Max power

7.5Kw

5Kw, 7.5Kw

Electric controller

AC programmable controller

SEVCON

GEL battery

Over 600 deep-cycle 200Ah at 80% DOD

150Ah

Basic equipment

Transmission model

Automatic Stepless

Front windshield

Front suspension

Independent Dual A Arm

Rear windshield

Rear suspension

Independent Dual A Arm

Half doors, Roof

Steering gear type

Rack and pinion steering gear, EPS

Winch 3000lbs

Service brake

Hydraulic dual circuits, front/rear disc

Winch 3500lbs

Parking brake

Rear wheel edge brake

Enclosed doors

Wheels and tire

Front 25*8-14, Rear 26*10-14

Grass tire 23x10.5-12

Charger type

on-board 110-240V, 6-8 hours IP66 CE

LED top light bar

Lights & Signals

LED(turning、position、braking、lighting)

Dump bed

Ventilation

Heater

Multimedia

FM with MP3
