Inside Dimension: 6900*3900*2700mm (L*W*H))
Outside Dimension: 7000*5350*3400mm (L*W*H).
Main door: 3-folds, 3000*2650mm(W*H).
Personal door: 1 unit 650*1800mm(W*H).
Wall Panels: EPS with double-ply plate, tongue and groove construction, thickness: 50mm.
basement and floor: Galvanized steel assemble, height is 300mm, complete grilles, 2PCS ramps, 1060*1750mm(W*L).
Lighting: Side upper intake air, aluminium alloy frame, coated steel.
Intake air fan: 2*4KW double-intake centrifugal fans, air capacity: 24000m^3/h.
Extract air fan: 1*3KW double-intake centrifugal fan, air capacity: 20900m^3/h.
Heating system: RIELLO G20 oil burner, heating productivity: 200000Kcal/h, stainless steel heat exchanger, with anti-explosion hole for protection.
Working temperature: 80 celsius degree, electric damper from spraying to baking cycle.
Filter system: Pre-filter, high efficiency filter(ceiling filter).
Control System: Lighting switch, spraying, heat spraying, baking temperature controller, time setting, emergency stop, temperature limimt controller.
Total Power: 12.9KW.
