Product Details

Model number		MSWX-110U	MSWX-180U	MSWX-380V	MSWX-450V	MSWX-760V
Hot water supply（L/H）		340	500	1150	1520	2150
Heating capacity(KW)		10.6	18	38	45	80
Electrical performance	Power supply	220V~3N/50HZ	380V～3N/50Hz	380V～3N/50Hz	380V～3N/50Hz	380V～3N/50Hz
	Rated input power(KW)	2.8	4.5	9.2	11.2	17.6
	Rated input Current(A)	5.6	8.6	17.2	21	35
Evaporator	Type	hydraulic fin	hydraulic fin	hydraulic fin	hydraulic fin	hydraulic fin
compressor	Brand	Copeland	Copeland	Copeland	Copeland	Copeland
	Quantity	1	1	2	2	3
	Type	scroll	scroll	scroll	scroll	scroll
Condenser		Titanium PVC heat exchanger	Titanium PVC heat exchanger	Titanium PVC heat exchanger	Titanium PVC heat exchanger	Titanium PVC heat exchanger
Fan motor ( Aluminum alloy)	Quantity	1	1	1	1	2
Fan motor ( Aluminum alloy)	Input power（W）	180	320	820	820	680
Unit Dimension	Length(mm)	680	820	1220	1220	1650
	Width(mm)	680	820	1020	1100	1100
	Height(mm)	880	1050	1730	1930	1930
Host weight(Kg)	Net weight（KG）	128	175	420	460	620
Host weight(Kg)	Gross weight（KG）	138	187	435	480	640
Rated water temperature		38	38	38	38	38
Maximum water temperature		45	45	45	45	45
Noise level(dB(A) )		≤54	≤56	≤60	≤61	≤64
Rated heating test condition:Ambient temperature DB ( dry bulb) 20°C, WB (wet bulb) 15°C, water input at 15°C. Output water temperature at 30°C
