Specification
Size:17cm*8.5cm*20cm
Weight:560g (battery not included)
Transmitting on 2.4G band
Modulation:FHSS
Operating system: 2-stick, 7-channel system
Power supply: 12V battery (8 pieces 5# batteries)
Current drain: 87mA(Energy Saving)
Standard Channel sequence
Brief Introduction
Channel 1: Aileron; Channel 2: Elevator; Channel 3: Throttle; Channel 4: Rudder
1.Both helicopter model and airplane model are available.
2.Function and performance updated with better safety.
3.Faster response.
4.All seven Channels have trim setting function and none interference between one another from channel 1 to channel 6 under CCPM mode.
5. Transmitter hops spectrum while powering on
6.Transmitter will detect whether the current spectrum channel was occupied when its power on, and it will hop to the next one until which it’s not occupied. The receiver will search and match with the transmitter which shares the same identity code.
7.Code matches wirelessly
8.Each transmitter has a unique identity code of its own, the receiver will search and bind with the nearest transmitter while pressing the code matching button on it. There is no need to match again in future use once its matching successfully.
9.High anti-interference capability
10. Adoption of FHSS technology makes our products have excellent anti-interference capability, and helps the models always be in control easily.
11.High suppression ratio of Adjacent Channels
12. Fully comply with FCC&CE standards
13. Stable RF range
14. With FHSS technology, its control range reaches 350 meters on ground and 700 meters in air.
15. Throttle on right/left-hand interchangeable.
16. LCD screen, manual programming is available. (Model type ACRO: model select/ data reset/ model type select/ model name, reversing, dual rates/ exponentials, end point adjustments, trim, normal throttle curve,programmable mix 1,programmable mix 2, flaperon mixing, flap trim, v-tail mixing, elevon mixing and auxiliary function.   Model type HELI: model select/ data reset/ model type select/ model name, reversing, dual rates/ exponentials, end point adjustments, trim, normal throttle curve, normal pitch curve, idle-up throttle curve, idle-up pitch curve, throttle hold, revolution mixing, gyro sensitivity, swash-throttle mixing/ swashplate types and auxiliary function.)
17. Low-battery warning function
18. The low battery alarm continuously beeps and LED flashes when voltage drops to 8.6V. 14.Trainer cable, power charging jack.
